| Dimensions |
|---|
| Full Length(mm): | 2180 mm |
| Full Width(mm): | 800 mm |
| Full Height(mm): | 1080 mm |
| Wheelbase(mm): | 1370 mm (Long wheelbase) |
| Ground Clearance(mm): | 135 mm |
| Fuel Tank Capacity(litre): | 15.5 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 187 Kg |
| Engine Type: | Single Cylinder, 4 stroke,Twinspark |
| Displacement CC: | 499 CC (Good) |
| Max Power: | 21 KW ( 27.2 BHP) @ 5250 RPM |
| Max Torque: | 41.3 Nm @ 4000 RPM |
| Bore x Stroke: | 84 x 90 |
| Carburettor: | Keihin Electronic Fu |
| Compression Ratio: | 8.5:1 |
| Starting: | Electric & Kick |
| Ignition: | Digital Electronic I |
| Clutch: | Wet, multi-plate |
| Gear Box: | 5 Speed constant mesh |
| Chassis Type: | Single downtube, using engine as stressed member |
| Front Suspension: | Telescopic, 35mm forks, 130mm travel |
| Brakes |
|---|
| Rear Suspension: | Twin gas charged shock absorbers with 5-step adjustable preload, 80mm travel |
| Front Brakes: | 280mm Disc, 2-Piston caliper |
| Wheels & Tyres |
|---|
| Rear Brakes: | 153mm Drum, Single Lead Internal Expanding |
| Tyre Size Front: | 90/90 - 19(Domestic), 90/90 - 18(Export) |
| Electricals |
|---|
| Tyre Size Rear: | 120/80 - 18(Domestic), 110/80 - 18(Export) |
| Battery: | 12 volt, 14 Ah |
| Head Light: | 60 W / 55 W, HALOGEN |
| Tail Stop Lamp: | 21 W / 5 W |
| Other Features |
|---|
| Features: |
| | 500cc, single cylinder, 4 stroke, spark ignition, air cooled, OHV engine produces 41.3 Nm of torque, Headlight casing features the Tiger Eye Lamps for the Bullet look. The headlamp is traditional but with a powerful halogen bulb to provide good illumination, Speedometer and Fuel warning indicator for the EFI system are integrated into the die-cast headlight casing. The speedometer features classic English font, Single saddle seat with springs provides maximum comfort for a luxurious and relaxing ride, Aesthetically designed short silencer for that 1950’s look. Available as an optional accessory for off-road use only & Finely crafted tank with post war era graphics and thigh pads make for a vintage look. |
| Colors: | Desert Brown |
