| Dimensions |
|---|
| Full Length(mm): | 2030 mm |
| Full Width(mm): | 760 mm |
| Full Height(mm): | 1070 mm |
| Wheelbase(mm): | 1320 mm |
| Ground Clearance(mm): | 165 mm (High Ground Clearance) |
| Fuel Tank Capacity(litre): | 17.5 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 126 Kg (Heavy) |
| Engine Type: | CC-VTi, 3 Valve, 4 Stroke |
| Displacement CC: | 124.8 CC |
| Max Power: | 7.7 KW (10.3 BHP) @ 7500 RPM |
| Max Torque: | 10 Nm @ 6000 RPM |
| Bore x Stroke: | 54.5 x 53.5 |
| Carburettor: | Ucal Mikuni VM20 |
| Compression Ratio: | 9.5:1 |
| Starting: | Electric |
| Ignition: | High energy IDI |
| Clutch: | Multi-plate wet |
| Gear Box: | 4 Speed constant mesh |
| Front Suspension: | Telescopic Oil Damped |
| Brakes |
|---|
| Rear Suspension: | 5 way adjustable Hydraulic |
| Front Brakes: | Drum - 130 mm dia, Disc |
| Wheels & Tyres |
|---|
| Rear Brakes: | Drum - 130 mm dia |
| Rim Size Front: | 2.75 X 18 |
| Rim Size Rear: | 3.00 x 18 |
| Tyre Size Front: | 90/90 x 17" |
| Electricals |
|---|
| Tyre Size Rear: | 100/90 - 17" |
| Battery: | 12V, 5Ah |
| Head Light: | 12V - 35/35W ( Halogen bulb ) |
| Tail Stop Lamp: | 12V 21 W/35W |
| Other Features |
|---|
| Tail Signal Lamp: | 12V, 16W/10W |
| Features: |
| | Digital Console, Electric Start, New Stylish Look, 3V CCVTi 125 cc Engine & Front Disc Brakes |
| Colors: | Elite Blue, Scarlet Red, Mica Black |
