| Dimensions |
|---|
| Full Length(mm): | 2085 mm |
| Full Width(mm): | 730 mm |
| Full Height(mm): | 1105 mm |
| Wheelbase(mm): | 1300 mm |
| Ground Clearance(mm): | 165 mm (High Ground Clearance) |
| Engine |
|---|
| Kerb Weight(Kg): | 139 Kg |
| Engine Type: | Air-cooled, 4-stroke single cylinder OHC |
| Displacement CC: | 177.4 CC (Good) |
| Max Power: | 12.52 KW (17.03 BHP) @ 8500 RPM |
| Max Torque: | 15.5 Nm @ 6500 RPM |
| Bore x Stroke: | 62.5 x 57.8 |
| Carburettor: | UCAL BS-29 |
| Compression Ratio: | 9.5:1 |
| Starting: | Kick & Electric Star |
| Ignition: | IDI-Dual mode digita |
| Clutch: | Multi-plate wet |
| Chassis Type: | Double Cradle SynchroSTIFF |
| Front Suspension: | Telescopic Fork |
| Brakes |
|---|
| Rear Suspension: | Monotube Inverted Gas-filled shox (MIG) with spring aid |
| Front Brakes: | 270mm Petal Disc |
| Wheels & Tyres |
|---|
| Rear Brakes: | 200mm Petal Disc |
| Rim Size Front: | 1.85 x 17 Inch |
| Rim Size Rear: | 2.15 x 17 Inch |
| Tyre Size Front: | 90/90 x 17 |
| Electricals |
|---|
| Tyre Size Rear: | 110/80 x 17 |
| Other Features |
|---|
| Features: |
| | Radical Race Design Lighter, Muscled Tank, New muscled styling New Nocturnal-Blue Backlit Display, LED Head light, RTR 180 cc Powerful Engine & Petal Disc Brakes |
| Colors: | Black, Grey & White |
