| Dimensions |
|---|
| Full Length(mm): | 2012 mm |
| Full Width(mm): | 760 mm |
| Full Height(mm): | 1111 mm |
| Wheelbase(mm): | 1271 mm |
| Ground Clearance(mm): | 173 mm (High Ground Clearance) |
| Fuel Tank Capacity(litre): | 13 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 128 Kg (Heavy) |
| Engine Type: | Air Cooled, 4 Stroke, SI Engine |
| Displacement CC: | 124.7 CC |
| Max Power: | 8.65 KW (11.6 BHP) @ 8000 RPM |
| Max Torque: | 11.2 Nm @ 6250 RPM |
| Carburettor: | PGM – FI electronic |
| Starting: | Self start |
| Ignition: | Full Transistorized |
| Gear Box: | 5 Speed constant mesh |
| Chassis Type: | Advanced Design Diamond Frame |
| Front Suspension: | Telescopic hydraulic fork |
| Brakes |
|---|
| Rear Suspension: | 3 Step Spring Loaded Hydraulic Shock Absorber with box type rectangular swing arm |
| Front Brakes: | Dia 240 mm Disc |
| Wheels & Tyres |
|---|
| Rear Brakes: | Dia 130 mm Drum |
| Tyre Size Front: | 80 / 100 - 17 46P |
| Electricals |
|---|
| Tyre Size Rear: | 100/90 - 17 55P |
| Battery: | 12V - 6 Ah/ MF |
| Head Light: | 12V - 35/35W ( Halogen bulb ) |
| Other Features |
|---|
| Features: |
| | PGM FI Technology with Premium 3D Emblem, Viscous Air Filter, Sense of Inclination, Self Diagnosis, Maintenence Free Battery & Winder Tubeless Tyres with Black Allay Wheels |
| Colors: | Red |
