| Dimensions |
|---|
| Full Length(mm): | 2110 mm |
| Full Width(mm): | 805 mm |
| Full Height(mm): | 1175 mm |
| Wheelbase(mm): | 1350 mm (Long wheelbase) |
| Ground Clearance(mm): | 159 mm (High Ground Clearance) |
| Fuel Tank Capacity(litre): | 17 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 159 Kg |
| Engine Type: | Air cooled, 4 - stroke single cylinder OHC, fuel injection |
| Displacement CC: | 223 CC (Good) |
| Max Power: | 13.15 KW (17.6 BHP) @ 7000 RPM |
| Max Torque: | 18.35 Nm @ 6000 RPM |
| Bore x Stroke: | 65.5 x 66.2 |
| Compression Ratio: | 9.0 : 1 |
| Starting: | Self start |
| Ignition: | DC – FTIS (Full Tran |
| Clutch: | Multi-plate wet |
| Gear Box: | 5 Speed constant mesh |
| Chassis Type: | Diamond Frame |
| Front Suspension: | Telescopic hydraulic shock absorbers |
| Brakes |
|---|
| Rear Suspension: | Swing arm with 5 step adjustable IGRS system |
| Front Brakes: | Disc, Dia 276 mm |
| Wheels & Tyres |
|---|
| Rear Brakes: | Disc Dia 240 mm |
| Rim Size Front: | 18 x 1.85, 5 Spoke cast wheel |
| Rim Size Rear: | 18 x 2.15, 5 Spoke cast wheel |
| Tyre Size Front: | 80 / 100 x 18 – 47 P tubeless |
| Electricals |
|---|
| Tyre Size Rear: | 100 / 90 x 18 – 56 P tubeless |
| Battery: | 12 V - 6 Ah, MF 7 (MF battery) |
| Head Light: | 12 V -35 W / 35W - Halogen bulb (Multi – reflector D.C type) |
| Other Features |
|---|
| Features: |
| | Astra gold front and rear disc plates, Aerodynamic design for superior handling at high speeds, Multi – Functional digital console with blue iIIumination and personalised message, Sporty full body cowl with body-coloured rear-view mirrors, Excellent visibility and less prone to damage, High intensity integrated LED tail light with integrated clear lens indicators |
| Colors: | Candy Blazing Red, Panther Black Metallic, Spot Light White, Vibrant Orange |
