| Dimensions |
|---|
| Full Length(mm): | 2125 mm |
| Full Width(mm): | 755 mm |
| Full Height(mm): | 1160 mm |
| Wheelbase(mm): | 1355 mm (Long wheelbase) |
| Ground Clearance(mm): | 150 mm |
| Fuel Tank Capacity(litre): | 17 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 150 Kg |
| Engine Type: | Air-cooled, 4-stroke single cylinder OHC |
| Displacement CC: | 223 CC (Good) |
| Max Power: | 12.68 KW (17 BHP ) @ 7000 RPM |
| Max Torque: | 18.35 Nm @ 6000 RPM |
| Bore x Stroke: | 65.5 x 66.2 |
| Carburettor: | VE, constant vacuum |
| Compression Ratio: | 9:1 |
| Starting: | Self & Kick |
| Ignition: | AMI - Advanced Micro |
| Clutch: | Multi-plate wet |
| Gear Box: | 5 Speed constant mesh |
| Chassis Type: | Diamond Frame |
| Front Suspension: | Telescopic hydraulic shock absorbers |
| Brakes |
|---|
| Rear Suspension: | Swing arm with 5 step adjustable hydraulic shock absorbers |
| Front Brakes: | Disc, Dia 276 mm Disc |
| Wheels & Tyres |
|---|
| Rear Brakes: | Internal expanding shoe type (130 mm) |
| Tyre Size Front: | 2.75 x 18 -42P |
| Electricals |
|---|
| Tyre Size Rear: | 100/90 x 18 - 56P |
| Battery: | 12 V - 6 Ah, MF 7 (MF battery) |
| Head Light: | 35W / 35W - Halogen bulb (Multi-reflector -D.C type) |
| Tail Stop Lamp: | 5 / 21W x 2 Nos (Multi reflector) |
| Other Features |
|---|
| Tail Signal Lamp: | 21W x 4 Nos (Amber bulb) (Clear lens multi-reflector) |
| Features: |
| | Exciting new graphics, Sporty undercowl, Large diameter front-wheel disk brake, Enhanced visor |
| Colors: | Daring Yellow, Power Black, Sports Red, Spotlight White, Ebony Grey |
