| Dimensions |
|---|
| Full Length(mm): | 2080 mm |
| Full Width(mm): | 765 mm |
| Full Height(mm): | 1325 mm |
| Wheelbase(mm): | 795 mm |
| Ground Clearance(mm): | 145 mm |
| Fuel Tank Capacity(litre): | 14.6 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 146 Kg |
| Engine Type: | Air-cooled, 4-stroke single cylinder OHC |
| Displacement CC: | 149.2 CC (Good) |
| Max Power: | 10.6 KW (14.2 BHP) @ 8500 RPM |
| Max Torque: | 12.80 Nm @ 6500 RPM |
| Bore x Stroke: | 57.3 x 57.8 |
| Carburettor: | CV Type |
| Compression Ratio: | 9.1: 1 |
| Starting: | Self start |
| Ignition: | AMI - Advanced Micro |
| Clutch: | Multi-plate wet |
| Gear Box: | 5 Speed constant mesh |
| Chassis Type: | Tabular, diamond type |
| Front Suspension: | Telescopic hydraulic shock absorbers |
| Brakes |
|---|
| Rear Suspension: | Swing arm with nitrox GRS (Gas reservoir suspension) |
| Front Brakes: | Dia 240 mm Disc |
| Wheels & Tyres |
|---|
| Rear Brakes: | Dia 220 mm Disc, Dia 130 mm |
| Rim Size Front: | 18 x 1.85, 5 spoke cast wheels |
| Rim Size Rear: | 18 x 2.15, 5 spoke cast wheels |
| Tyre Size Front: | 2.75 x 18 – 42 P, Tubeless tyres |
| Electricals |
|---|
| Tyre Size Rear: | 80 / 100 X 18 - 47 P, Tubeless tyres |
| Battery: | 12 V -4 Ah, MF battery |
| Head Light: | 12 V -35 W / 35W - Halogen bulb (Multi – reflector type) |
| Tail Stop Lamp: | 12 V -0.5 W / 4.1W LED lamp |
| Other Features |
|---|
| Tail Signal Lamp: | 12 V -10 W (Amber bulb) x 4 nos. (Multi – reflector clear lens) |
| Features: |
| | Flared fenders and tubeless tyres, Contoured visor, Analog-Digital speed panel in chrome-tinged flame orange console, Red hot LED tail light, Ridged muffler cover with front and rear disc brakes |
| Colors: | Blazing Red, Bold Brown, Ebony Grey, Force Silver, Panther Black, Sports Red |
| Service: | Break-through service package with 3 years or 40000 kms. warranty period and 6 free service benefits up to 18 months |
