| Dimensions | ||
|---|---|---|
| Full Length(mm): | 1750 mm | |
| Full Width(mm): | 705 mm | |
| Full Height(mm): | 1100 mm | |
| Wheelbase(mm): | 1240 mm | |
| Ground Clearance(mm): | 125 mm | |
| Fuel Tank Capacity(litre): | 5 litre | |
| Engine | ||
| Kerb Weight(Kg): | 104 Kg (Heavy) | |
| Engine Type: | Air-cooled, 4-stroke single cylinder OHC | |
| Displacement CC: | 102 CC | |
| Max Power: | 5.03 KW @ 7000 RPM | |
| Max Torque: | 7.85 Nm @ 5000 RPM | |
| Bore x Stroke: | 50.0 x 52.0 | |
| Compression Ratio: | 9.0 : 1 | |
| Starting: | Self start | |
| Ignition: | CDI | |
| Gear Box: | Variomatic drive (2.51 – 0.81) | |
| Chassis Type: | High rigidity under bone type | |
| Front Suspension: | Bottom link with spring-loaded hydraulic damper | |
| Brakes | ||
| Rear Suspension: | Swing arm with spring-loaded hydraulic damper | |
| Front Brakes: | Internal expanding shoe type (130 mm) | |
| Wheels & Tyres | ||
| Rear Brakes: | Internal expanding shoe type (130 mm) | |
| Rim Size Rear: | 10 x 2.15 | |
| Tyre Size Front: | 3.50 x 10 – 4 PR / 51 J (with tuff up tube) | |
| Electricals | ||
| Tyre Size Rear: | 3.50 x 10 – 4 PR / 51 J (with tuff up tube) | |
| Battery: | 12V-4 Ah | |
| Head Light: | 12V – 35W / 35W – Halogen bulb (Multi – reflector type) | |
| Other Features | ||
| Tail Signal Lamp: | 12V – 21W (Amber bulb) x 4 nos ( Multi – reflector, clear lens) | |
| Features: | ||
Pleasure of Style Pleasure of Stress-free Riding Pleasure of Space | ||
| Colors: | Candi Blazing Red And Black, Candi Blazing Red, Dream Orange, Ebony Grey, Light Purple, Sparkle | |
| Service: | Is warranted for a period of 2 years or 24,000 kms, whichever is earlier, from the date of purchase. Also 6 Free Services. | |
| Mileage Highway: | 58.4 km/l | |
| Mileage City: | 24.41 km/l | |
| Mileage Overall: | 49.6 km/l | |
