| Dimensions |
|---|
| Full Length(mm): | 2100 mm |
| Full Width(mm): | 820 mm |
| Full Height(mm): | 1160 mm |
| Wheelbase(mm): | 1360 mm (Long wheelbase) |
| Ground Clearance(mm): | 245 mm (High Ground Clearance) |
| Fuel Tank Capacity(litre): | 13.7 litre (Large Fuel Tank) |
| Engine |
|---|
| Engine Type: | Air cooled, 4- stroke single cylinder OHC , Self start |
| Displacement CC: | 149.2 CC (Good) |
| Max Power: | 9.7 KW (13.2 Ps) @ 7500 RPM |
| Max Torque: | 13.4 Nm @ 5000 RPM |
| Ignition: | D.C - CDI Ignition S |
| Gear Box: | 5 Speed constant mesh |
| Front Suspension: | Telescopic Hydraulic Shock Absorbers |
| Brakes |
|---|
| Rear Suspension: | Swing Arm with Mono Suspension with Nitrox |
| Front Brakes: | Dia 240 mm Disc |
| Wheels & Tyres |
|---|
| Rear Brakes: | Internal expanding shoe type (110 mm) |
| Tyre Size Front: | 90 / 90 x 19 - 52 P |
| Electricals |
|---|
| Tyre Size Rear: | 110 / 90 x 17 - 60 P |
| Battery: | 12 V - 4 Ah, MF Battery |
| Head Light: | 12 V - 35 W / 35 W - Halogen Bulb (Multi -Reflector Type) |
| Tail Stop Lamp: | 12V - 0.5 W / 4.1 W LED Lamp |
| Other Features |
|---|
| Tail Signal Lamp: | 12 V - 10 W (Amber Bulb) x 4 nos (Multi-Reflector-Clear Lens) |
| Features: |
| | High torque ATFT engine and high ground clearance for rough terrain riding, Raised fender and large diameter front wheel with “stud pattern’ type tyres, Sturdier front suspension with long stroke and large front disc brake for cross country riding, Nitrox gas-filled mono shock rear suspension, Straight pull spokes at the rear for tough terrains, Low maintenance sealed endless drive chain, Digital-analog combo meter console with ‘service due’ indicator, Sharp edgy graphics, Motocross seat, Sporty high mount muffler |
| Colors: | Terra Rossa,Grassland Green,Canyon Orange,Deep Sea Blue,Tar Black |
| Service: | Breakthrough service package with 3 years/40000 kms. warranty period. Plus, 6 Free service benefits up to 560 days. |
| Mileage Highway: | 55 km/l |
| Mileage City: | 40 km/l |
| Mileage Overall: | 45 km/l |
