| Dimensions |
|---|
| Full Length(mm): | 2160 mm |
| Full Width(mm): | 800 mm |
| Full Height(mm): | 1080 mm |
| Wheelbase(mm): | 1370 mm (Long wheelbase) |
| Ground Clearance(mm): | 135 mm |
| Fuel Tank Capacity(litre): | 14.5 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 187 Kg |
| Engine Type: | Single Cylinder, 4 stroke, Twinspark |
| Displacement CC: | 499 CC (Good) |
| Max Power: | 27.2 BHP @ 5250 RPM |
| Max Torque: | 41.3 Nm @ 4000 RPM |
| Bore x Stroke: | 84 × 90 |
| Compression Ratio: | 8.5:1 |
| Starting: | Electric & Kick |
| Ignition: | Digital Electronic I |
| Clutch: | Wet, multi-plate |
| Gear Box: | 5 Speed constant mesh |
| Chassis Type: | Single downtube, using engine as stressed member |
| Front Suspension: | Telescopic,35mm forks, 130mm travel |
| Brakes |
|---|
| Rear Suspension: | Twin gas charged shock absorbers with 5-step adjustable preload, 80mm travel |
| Front Brakes: | 280mm Disc, 2-Piston caliper |
| Wheels & Tyres |
|---|
| Rear Brakes: | 153mm Drum, Single Lead Internal Expanding |
| Tyre Size Front: | 90/90 - 19 inches |
| Electricals |
|---|
| Tyre Size Rear: | 120/80 - 18 inches |
| Battery: | 12 volt, 14 Ah |
| Head Light: | 60/55 W, HALOGEN |
| Tail Stop Lamp: | 12V, 21W/5W |
| Other Features |
|---|
| Features: |
| | Chrome front mudguard, Chrome dominates rear mudguard enhancing classic appeal, Unique Tan seat, available on this model only. Spring seat, with removable pillion seat, Finely crafted tank with post war era graphics and with generous chrome, Chrome tool box with classic design, 280MM disc brake |
| Colors: | Teal Green, Royal Maroon, Black, Desert Brown, Chrome, Rosso Chianti |
