| Dimensions |
|---|
| Full Length(mm): | 2140 mm |
| Full Width(mm): | 800 mm |
| Full Height(mm): | 1030 mm |
| Wheelbase(mm): | 1370 mm (Long wheelbase) |
| Ground Clearance(mm): | 135 mm |
| Fuel Tank Capacity(litre): | 13.5 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 180 Kg |
| Engine Type: | Single Cylinder, 4 stroke, Twinspark |
| Displacement CC: | 346 CC (Good) |
| Max Power: | 19.8 BHP @ 5250 RPM |
| Max Torque: | 28 Nm @ 4000 RPM |
| Bore x Stroke: | 70 x 90 |
| Compression Ratio: | 8.5:1 |
| Starting: | Kick |
| Ignition: | Transistorized Coil |
| Clutch: | Wet, multi-plate |
| Gear Box: | 5 Speed constant mesh |
| Chassis Type: | Single downtube, using engine as stressed member |
| Front Suspension: | Telescopic,35mm forks, 130mm travel |
| Brakes |
|---|
| Rear Suspension: | Twin shock absorbers with 5-step adjustable preload, 80mm travel |
| Front Brakes: | 7 inch Twin lead internal expanding drum brake |
| Wheels & Tyres |
|---|
| Rear Brakes: | 153mm Drum, Single Lead Internal Expanding |
| Electricals |
|---|
| Battery: | 12 volt, 14 Ah |
| Head Light: | 35 W / 35 W, HALOGEN |
| Tail Stop Lamp: | 12V, 21W/5W |
| Other Features |
|---|
| Features: |
| | Modern UCE with heavier crank-shaft, Traditional mudguard with subframe, More pronounced Thump from exhaust note, Black tank with hand painted pin striping. Motif on tank faithful to period specific looks |
| Colors: | Black |
