| Dimensions |
|---|
| Full Length(mm): | 2200 mm |
| Full Width(mm): | 800 mm |
| Full Height(mm): | 1120 mm |
| Wheelbase(mm): | 1370 mm (Long wheelbase) |
| Ground Clearance(mm): | 135 mm |
| Fuel Tank Capacity(litre): | 14.5 litre (Large Fuel Tank) |
| Engine |
|---|
| Kerb Weight(Kg): | 185 Kg |
| Engine Type: | Single Cylinder, 4 stroke |
| Displacement CC: | 499 CC (Good) |
| Max Power: | 27.2 BHP @ 5250 RPM |
| Max Torque: | 41.3 Nm @ 4000 RPM |
| Bore x Stroke: | 84 × 90 |
| Compression Ratio: | 8.5:1 |
| Starting: | Electric & Kick |
| Ignition: | Digital Electronic I |
| Clutch: | Wet, multi-plate |
| Gear Box: | 5 Speed constant mesh |
| Chassis Type: | Single downtube, using engine as stressed member |
| Front Suspension: | Telescopic,35mm forks, 130mm travel |
| Brakes |
|---|
| Rear Suspension: | Twin gas charged shock absorbers with 5-step adjustable preload, 80mm travel |
| Front Brakes: | 280mm Disc, 2-Piston caliper |
| Wheels & Tyres |
|---|
| Rear Brakes: | 153mm Drum, Single Lead Internal Expanding |
| Tyre Size Front: | 90/90 - 19 inches |
| Electricals |
|---|
| Tyre Size Rear: | 100/90-19 inches |
| Battery: | 12 volt, 14 Ah |
| Head Light: | 60/55 W, HALOGEN |
| Tail Stop Lamp: | 12V, 21W/5W |
| Other Features |
|---|
| Features: |
| | The all new Unit Construction Engine with hydraulic tappets, Fuel Injection System from Keihin, Japan, 5 speed gear box featuring a seven-plate wet clutch for easy operation, Bullet nacelle with Tiger Eyes and multi focal headlamp unit, Gas filled shock absorbers, Bigger 19 inch wire wheels for that classic stance with disc brake kit as standard |
| Colors: | Black |
